JIC Female 74°Cone SAEJ514
PA RT NO. |
T |
HOSE BORE |
|
DIMENSIONS |
||||
THREAD T |
DN |
DASH |
|
L |
|
|
S1 |
|
S26711-04-04 |
7/16"X20 |
6 |
04 |
|
15 |
|
|
14 |
S26711-05-04 |
1/2"X20 |
6 |
04 |
|
15.5 |
|
|
17 |
S26711-05-05 |
1/2"X20 |
8 |
05 |
|
15.5 |
|
|
17 |
S26711-06-04T |
9/16"X18 |
6 |
04 |
|
15.5 |
|
|
19 |
S26711-06-05 |
9/16"X18 |
8 |
05 |
|
15.5 |
|
|
19 |
S26711-06-06 |
9/16"X18 |
10 |
06 |
|
15.5 |
|
|
19 |
S26711-07-06 |
9/16"X18 |
13 |
08 |
|
16 |
|
|
19 |
S26711-08-06T |
3/4"X16 |
10 |
06 |
|
17.5 |
|
|
22 |
S26711-08-08 |
3/4"X16 |
13 |
08 |
|
18 |
|
|
22 |
S26711-08-10 |
3/4"X16 |
16 |
10 |
|
19 |
|
|
22 |
S26711-10-08T |
7/8"X14 |
13 |
08 |
|
18 |
|
|
27 |
S26711-10-10 |
7/8"X14 |
16 |
10 |
|
20 |
|
|
27 |
S26711-10-12 |
7/8"X14 |
19 |
12 |
|
20 |
|
|
27 |
S26711-12-08T |
1.1/16"X12 |
13 |
08 |
|
20 |
|
|
32 |
S26711-12-10T |
1.1/16"X12 |
16 |
10 |
|
21.5 |
|
|
32 |
S26711-12-12 |
1.1/16"X12 |
19 |
12 |
|
21.5 |
|
|
32 |
S26711-14-12T |
1.3/16"X12 |
19 |
12 |
|
21.5 |
|
|
36 |
S26711-16-12T |
1.5/16"X12 |
19 |
12 |
|
22 |
|
|
41 |
S26711-16-16 |
1.5/16"X12 |
25 |
16 |
|
23 |
|
|
41 |
S26711-20-16T |
1.5/8"X12 |
25 |
16 |
|
25 |
|
|
50 |
S26711-20-20 |
1.5/8"X12 |
32 |
20 |
|
26 |
|
|
50 |
S26711-24-20T |
1.7/8"X12 |
32 |
20 |
|
26.5 |
|
|
60 |
S26711-24-24 |
1.7/8"X12 |
38 |
24 |
|
26.5 |
|
|
60 |
S26711-32-24T |
2.1/2"X12 |
38 |
24 |
|
26.5 |
|
|
75 |
S26711-32-32T |
2.1/2"X12 |
51 |
32 |
|
27 |
|
|
75 |
Note:1.For use with braided hoses. 2. If use with spiral hoses, hose fitting series number is S26712-XX-XX. |
||||||||
