Hydraulic joint

Classification: Hydraulic hoses, high-pressure ball valves, special quick couplings, sleeve type couplings, welded couplings, high-pressure hoses, transition couplings, sleeve type couplings, three-way couplings, non-standard couplings, flared couplings, right angle couplings, rotary couplings, quick couplings, stainless steel couplings, and copper couplings.
The important step in the pre-installation of the ① sleeve-type pipe joint directly affects the reliability of the seal. Generally, a dedicated preheater is required. Small diameter joints can be pre-installed on a vise. The specific method is to use a joint as the base press the nut and clamp onto the pipe. There are main types such as sleeve-type straight pipe fittings, sleeve-type end straight connectors, and sleeve-type three-way pipe fittings. The author found that even for a batch of goods from the same manufacturer, the depth of the conical holes on these types of joint bodies is often different, resulting in leakage, which is often overlooked. The correct approach is to use a certain type of joint body to connect one end of the pipe and pre-install the corresponding connection end with the same type of joint, which can minimize leakage problems The end face of the pipe should be flush. After the pipe is sawn off, it should be polished flat on grinding wheels and other tools, and burrs should be removed. It should be cleaned and blown clean with high-pressure air before use During pre-installation, the coaxiality between the pipe and the joint body should be maintained as much as possible. If the pipe deviates too much, it can also cause sealing failure The pre-installation force should not be too strong, and the inner edge of the sleeve should just fit into the outer wall of the pipe. The sleeve should not have obvious deformation. When connecting pipelines, assemble them according to the specified tightening force. The tightening force of the ∅ 6-1 sleeve is 64-1 15n, 16 ∅ MMR 259n, and the tightening force of the ∅ 18mm sleeve is 450n. If the sleeve deforms severely during pre-installation, it will lose its sealing effect.
